PCB & PCBA Solution Directory

Each solution maps a common PCB or PCBA requirement to a clear manufacturing route, relevant capability references and the RFQ information needed for engineering review.

QT-24H

Quick-Turn PCB Prototype

Quick-turn PCB prototyping for urgent design verification, engineering samples and NPI builds, with DFM review before production and a controlled path to repeat manufacturing.

  • Prototype layer capabilityEngineering review up to 60-layer rigid PCB
  • Minimum line / space3 / 2.5 mil
Open solution
SI-04L

4-Layer Controlled Impedance PCB

A 4-layer controlled impedance PCB solution for single-ended and differential signals, with stack-up, reference-plane and trace-geometry review before manufacturing.

  • Impedance tolerance±8%
  • Minimum line / space3 / 2.5 mil
Open solution
HS-06L

6-Layer High-Speed PCB

A 6-layer high-speed PCB solution with controlled-impedance stack-up, reference-plane and back-drill review for signal-integrity-critical digital interfaces.

  • Impedance tolerance±8%
  • Back drillingTarget-layer and depth review based on stack-up
Open solution
HDI-1N1

1+N+1 HDI Microvia PCB

A 1+N+1 HDI PCB solution using laser-drilled microvias for compact layouts, high-density routing and fine-pitch BGA fan-out, subject to stack-up and DFM review.

  • HDI build-up1+N+1 sequential lamination
  • Laser microvia3–5 mil
Open solution
RF-4350

Rogers RO4350B RF PCB

A Rogers RO4350B RF PCB solution for microwave, antenna and high-frequency signal chains, with low-loss material, stack-up and controlled-impedance review before manufacturing.

  • Material familyRogers RO4003C · RO4350B
  • Impedance tolerance±8%
Open solution
HYB-RF

FR-4 + Rogers Hybrid RF PCB

A mixed-material FR-4 and Rogers RF PCB solution that uses high-frequency laminates where signal performance matters while retaining a practical multilayer structure and controlled-impedance design.

  • MaterialsFR-4 families + Rogers RO4003C / RO4350B
  • Thickness rangeRigid PCB 0.3–8.0 mm
Open solution
FLEX-ML

Multilayer Flexible PCB

A multilayer flexible PCB solution using polyimide construction for compact, space-constrained and moving interconnects, with bend, routing and stack-up requirements confirmed through DFM review.

  • Flex layer capabilityUp to 12 layers
  • Flex thickness range0.1–1.0 mm
Open solution
RFX-06L

6-Layer Rigid-Flex PCB

A 6-layer rigid-flex PCB solution integrating rigid and flexible regions for compact assemblies, reduced connector count and controlled flex-to-rigid transitions, subject to stack-up and DFM review.

  • Flex layer capabilityUp to 12 layers
  • Blind / laser microvia3–5 mil
Open solution
MCPCB-AL

Aluminum-Core LED PCB

An aluminum-core LED PCB solution for applications where heat transfer, thermal management and mechanical construction are critical to reliable LED operation.

  • Aluminum-core materialBOYU aluminum-base laminate
  • PCB thickness range0.3–8.0 mm
Open solution
HCP-06OZ+

Heavy-Copper Power PCB

A heavy-copper PCB solution for high-current power conversion, motor drives and industrial electronics where current-carrying capacity, thermal management and copper geometry are critical.

  • Copper weight capabilityRigid inner / outer: 1/3–28 oz
  • Line / spacing capabilityCopper-dependent process window
Open solution
AUTO-IATF

Automotive PCB Manufacturing under IATF 16949

An IATF 16949-based automotive PCB manufacturing path for vehicle control, sensing and power electronics, with documented process control, traceability and inspection.

  • Quality management systemIATF 16949:2016
  • IPC workmanship reviewClass 2 and Class 3
Open solution
PCBA-BOX

Turnkey PCBA & Box Build Assembly

A turnkey PCBA and box-build workflow connecting BOM review, component sourcing, PCB fabrication, SMT, THT, testing, conformal coating, final assembly and traceability.

  • Assembly processesSMT · THT · testing · conformal coating · box build
  • Sourcing modelsTurnkey · consigned · hybrid
Open solution
LIFE-CYCLE

Legacy PCB Redesign & Obsolete PCB Replacement

A controlled legacy PCB redesign and replacement path for obsolete components, missing manufacturing data, material substitutions and repeat production of long-life equipment.

  • Obsolescence reviewBOM risk · component substitution · material replacement · stack-up reconstruction
  • Manufacturing routePCB fabrication · component sourcing · PCBA · testing
Open solution

Published capability limits reflect JETFGO’s current manufacturing processes and are provided for initial selection. Final feasibility depends on the complete project data and engineering review.

REQUIREMENT-BASED SELECTION

Match Your PCB Requirements to the Right Manufacturing Route

Select the application environment, PCB construction and primary technical constraint. The selector recommends relevant manufacturing solutions before final feasibility is confirmed through DFM review.

Start PCB Requirement Check
RFQ / DFM

Discuss your next order directly with our factory.

Send the Gerber or ODB++, stackup, material, quantity, target date and test requirements. Our team will review feasibility and return a technical quotation for the order you manage.

Engineering reviewMaterial & stackupPrecision fabrication
